CHAIN ACTUATOR SUPERMASTER
Robust UCS Chain Actuator for Smoke and Natural Ventilation
The UCS SUPERMASTER electric actuator is engineered for powerful automation of large and heavy windows in commercial, industrial, and safety-critical environments. Featuring a double-link chain and delivering up to 400 N force, it is suitable for top-hung and bottom-hung windows with demanding stroke and load requirements.
The actuator includes a built-in LED indicator on the side cover to signal closed position, and allows manual stroke-end adjustment using a side knob. Thanks to dovetail slides and sliding brackets, the SUPERMASTER is quick and easy to install. Its advanced design ensures resistance to high loads even at long strokes (up to 1000 mm).
The 24V DC version is EN 12101-2 certified for use in smoke and heat exhaust ventilation (SHEV / NSHEV) systems, tested and validated by Istituto Giordano. For dual-actuator setups, it is compatible with the CP230 Coupling Control Unit.
Key Features – UCS SUPERMASTER
- 🔹 Max. force: 400 N
- 🔹 Strokes: 450 mm, 600 mm, 800, 1000 mm
- 🔹 Double-link chain for high-load endurance
- 🔹 LED indicator for closed position
- 🔹 Manual adjustment of closing position (side knob)
- 🔹 Dovetail slides for fast and secure installation
- 🔹 Suitable for top- and bottom-hung windows
- 🔹 24V version certified for EN 12101-2 (NSHEV / SHEV)
- 🔹 Compatible with UCS CP230 control unit for synchronized operation
Applications
- 🔹 Smoke and Heat Extraction (SHEV / NSHEV)
- 🔹 Industrial and commercial ventilation systems
- 🔹 Large top- and bottom-hung windows
- 🔹 Smart Building Integration
Need Help?
Use the form below to inquire about technical compatibility, project requirements, or to receive a custom configuration of the UCS SUPERMASTER actuator. Our team is ready to assist you.
Technical Specifications – UCS SUPERMASTER Chain Actuator
| Technical Characteristics | Supermaster 230V | Supermaster 24V |
| Power voltage | 230 Vca ± 10% | 24 Vdc ± 10% |
| Max applicable load in thrust | 400 N (300 N for 800mm stroke) | 400 N (300 N for 800mm stroke) |
| Max applicable load in traction | 400 N | 400 N |
| Stroke | 450 mm, 600 mm, 800 mm, 1000 mm | 450 mm, 600 mm, 800 mm, 1000 mm |
| Absorbed current | 0,8A | 2,0A |
| Idle translation speed | 23 mm/s | 20mm/s |
| Open/close feedback signal | - | yes |
| Electrical connection | 3 wires + earth | 2 wires + signaling |
| Parallel connection | yes | yes |
| Service type | S2 4min | S2 4min |
| Operating temperature (°C) | -5° + 50° | -5° + 50° |
| Protection Class | IP 20 | IP 20 |
| Stroke end | micro switches | micro switches |
| Safety stop | Thermic | Electronic |
