DUAL PUSH POINTS CHAIN ACTUATOR C260

Powerful Window Automation with Dual-Link Chain Technology

The TOPP C260 is a heavy-duty electric chain actuator featuring two double-link articulated chains housed in a sleek die-cast aluminum profile. Developed for large and wide windows, this actuator offers tailored profile lengths from 1550 mm to 4000 mm, ensuring precise fit and force distribution across the entire window structure.

With a maximum thrust force of 600 N and a stroke of up to 600 mm, the C260 is designed for demanding ventilation applications in commercial, industrial, and architectural environments. It operates on 230V~ 50Hz and includes an electronic end-of-stroke control in closing via current absorption, ensuring safe and accurate operation.

Ideal for top-hung and bottom-hung windows, the C260 provides high-performance automation with a robust yet refined appearance. The actuator is CE certified and engineered to meet the needs of modern window systems requiring enhanced power and aesthetics.

Key Features – TOPP C260

• 🔹 Max. thrust force: 600 N
• 🔹 Max. stroke: 600 mm
• 🔹 Voltage: 230V~ 50Hz
• 🔹 Dual double-link articulated chains for heavy-duty performance
• 🔹 Custom profile lengths from 1550 mm to 4000 mm
• 🔹 Electronic stroke-end control by current absorption (closing)
• 🔹 Elegant die-cast aluminum design
• 🔹 CE marked device

Applications

• 🔹 Large façade and roof windows
• 🔹 Commercial and public buildings
• 🔹 Architectural ventilation solutions
• 🔹 High-load window automation systems

Need Help?

Use the form below to ask about technical compatibility or to receive a tailored configuration of the TOPP C260. Our specialists are ready to help you with your window automation project.
