RACK ACTUATOR T-RACK
Robust and Powerful Actuator for Skylights, Domes and Louvers
The UCS T-RACK is a heavy-duty electric rack actuator engineered to operate large domes, top-hinged windows, skylights, and facade elements. With a powerful thrust of up to 1000 N and a stroke range from 350 mm to 1000 mm, this actuator delivers unmatched force and reliability in even the most demanding architectural projects.
Its versatile installation options include point brackets or sliding brackets, and its 12 mm square rack ensures a stable, high-load transmission. Optional configurations include a 1200 mm stroke and the F-SIGNAL version, which provides open/close feedback signals (dry contact) activated by current limit detection.
For applications requiring multiple push points, the T-RACK supports mechanical linkage using a transmission rod in Dual or Double Master-Slave configurations. Additionally, the Synchro T-RACK version features integrated speed synchronization electronics, enabling up to four actuators to work together without an external control box or connecting rod.
Rated at IP65, the T-RACK actuator is also available in a 24V RWA version compliant with EN 12101-2 for smoke and heat exhaust ventilation systems (SHEV).
Key Features – UCS T-RACK
- 🔹 Voltage options: 230V~ 50Hz or 24V DC
- 🔹 Thrust force: up to 1000 N
- 🔹 Stroke options: 350, 550, 750, 1000 mm (optional 1200 mm)
- 🔹 Optional F-SIGNAL version for position feedback
- 🔹 Compatible with mechanical or electronic synchronization
- 🔹 Rack section: 12 mm square
- 🔹 IP65 protection – resistant to dust and moisture
- 🔹 CE-marked and EN 12101-2 certified (24V RWA version)
Applications
- 🔹 Skylights, domes and top-hung windows
- 🔹 Natural ventilation and facade automation
- 🔹 Smoke and heat extraction (SHEV)
- 🔹 Multiple actuator synchronization for large openings
Need Help?
Use the form below to ask about product availability, system design or custom configuration options for the UCS T-RACK. Our team is ready to assist you.
Technical Specifications – UCS T-RACK Rack Actuator
|
Technical Characteristics |
T-RACK 230V | T-RACK 24V | SYNCHRO T-RACK 24V |
| Power voltage | 230V ~ 50Hz | 24 Vdc ± 10% | 24 Vdc ± 10% |
| Electrical connection | 3 wires + earth | 2 wires + signal | 5 wires |
| Recommended applicable load in thrust | 1000 N | 1000 N | 1000 N |
| Recommended applicable load in traction | 1000 N | 1000 N | 1000 N |
| Max applicable load (MASTER + SLAVE) | 1000 N | 1000 N | 1000 N |
| Max applicable load (MASTER + MASTER) | 2000 N | 2000 N | 2000 N |
| Max applicable load (4 X SYN T-RACK 24V) | - | - | ~4000 N |
| Strokes | 350,550,750,1000 mm | 350,550,750,1000 mm | 350,550,750,1000 mm |
| Absorbed current | 0,32 A | 1,5 A | 1,5 A |
| Idle translation speed | ~12,5 mm/s | ~12,5 mm/s | ~12,5 mm/s |
| Service type | S2 of 4 min | S2 of 4 min | S2 of 4 min |
| Protection Class | IP65 | IP65 | IP65 |
| Possibility of installing double push point on the same window | transmission rod | transmission rod | electronic |
| Parallel connection option | yes | yes | yes |
| Open/close feedback signal | - | yes | - |
| Stroke end | electronic | electronic | electronic |
| Safety stop | electronic | electronic | electronic |
| Color | silver | silver | silver |
